Dimensions and weights are subject to change due to ongoing technical development, and vary from country to country.
Standard Equipment
infinitely-variable transmission (submerged in grease), multi sowing wheels and inserts for reduced normal sowing, spur wheel drive seed level indicator, calibration system with crank handle, parking stands, from 3-m-machine on half-side switch off of seed shaft
Vitasem 251: 2.5 m working width - hopper 410 l Vitasem 301: 3.0 m working width - hopper 510 l Vitasem 401: 4.0 m working width - hopper 720 l
Perfect sowing system
The optimised shape of the metering peg
ensures the highest level of seed protection.
Drilling rapeseed with low seed counts
per square meter is carried out with optimal
plant populations.
Wide, funnel-shaped outlets above each metering
wheel
Precise feed down to the last grain – ideal performance
even with low quantities
Lowest residues
Seed does not slide across – excellent performance
on slopes
No partition plate required for rapeseed
Funnelled outlets provide for minimal
residual amounts and low minimum-fi ll
amounts. A suffi cient opening angle in the
bottom fl ap ensures that the metering area
is completely emptied.
„Overhead sowing“: For sowing fi ne grain
the direction of rotation of the sowing shaft
is changed (easy adjustment on side drive).
Small hollows on the rear of the sowing
wheel pegs take only one grain and drop
it overhead into the seed funnel. Principle:
sowing individual grains.
Trailed tines
"Perfect" and "Standard" tines have same mounting system
"Perfect" tines single row: alternate short and long V-tines– angle can be adjusted
"Standard" tines single row: straight tines – angle can be adjusted
VITASEM A seed drill is mounted on packer and guided by top link – parallelogram guided – packer and seed drill form a single unit
Gap between seed drill and scraper bar is minimised – compact unit
Driven by land wheel on left-hand side of machine – runs within 3 m working width
Central coulter pressure adjustment on left-hand side of machine with scale for reference Equal coulter pressure on front and rear gangs. Pressure springs attached to seed tubes – up to 25 kg pressure on coulters
Rugged, wide coulter arm mountings (85 mm) with replaceable bushings. Fastened using cast clamps attached to coulter rails using U-bolts
Depth roller available on option for limiting depth and repacking surface – straightforward depth adjustment using cotter pin – easy to fi t/remove.
