On steep ground, or on the flat, a EUROBOSS is always a good match. Tractors from 60 to 110 hp are sufficient for an impressive loading performance. Available as high or low–profile loader wagons and a knife bank with 31 knives.

On steep ground, or on the flat, a EUROBOSS is always a good match. Tractors from 60 to 110 hp are sufficient for an impressive loading performance. Available as high or low–profile loader wagons and a knife bank with 31 knives.


Technical data

 EUROBOSS 250 TEUROBOSS 250 HEUROBOSS 290 TEUROBOSS 290 HEUROBOSS 330 T
Length6,83 m6,83 m7,45 m7,45 m8,07 m
Width2,58 m2,36 m2,58 m2,36 m2,58 m
Height3,07 m3,26 m3,07 m3,26 m3,07 m
Height with opened tailgate3,31 m3,49 m3,31 m3,49 m3,31 m
Height folded down2,21 m2,39 m2,21 m2,39 m2,21 m
Number of scraper floor chains2 pcs.2 pcs.2 pcs.2 pcs.2 pcs.
Length loading area (Width 1,56)3,97 m3,97 m4,59 m4,59 m5,21 m
Loading volume (DIN 11741)16,1 m³16,1 m³18,7 m³18,7 m³21,3 m³
Number of knives max.31 pcs.31 pcs.31 pcs.31 pcs.31 pcs.
Theoretical chopped length43 mm43 mm43 mm43 mm43 mm
Pick-up recording width1,8 m1,8 m1,8 m1,8 m1,8 m
Track width2,09 m1,85 m2,09 m1,85 m2,09 m
Weight of basic version2700 kg2700 kg2825 kg2825 kg2950 kg
ChassisSingle axle Single axle Single axle Single axle Single axle
Single axle, 10 kph7500 kg7500 kg7500 kg7500 kg7500 kg
Single-axle, 25/40* kph, brakes7500 kg7500 kg7500 kg7500 kg7500 kg
Tandem-axle, 25/40 kph, brakes10000 kg10000 kg10000 kg10000 kg10000 kg
Single-axle, 30*/40** kph7500 kg7500 kg7500 kg7500 kg7500 kg
Tandem-axle, 30/40 kph*10000 kg10000 kg10000 kg10000 kg10000 kg
Note: *EU-2015/68, only with dual line brake system-----
 EUROBOSS 330 HEUROBOSS 370 TEUROBOSS 370 HEUROBOSS 330 D-TEUROBOSS 330 D-H
Length8,07 m8,69 m8,69 m8,07 m8,07 m
Width2,36 m2,69 m2,36 m2,58 m2,36 m
Height3,26 m3,07 m3,26 m3,07 m3,26 m
Height with opened tailgate3,49 m3,31 m3,49 m3,31 m3,49 m
Height folded down2,39 m2,21 m2,39 m2,21 m2,39 m
Number of scraper floor chains2 pcs.2 pcs.2 pcs.2 pcs.2 pcs.
Length loading area (Width 1,56)5,21 m5,83 m5,83 m5,21 m5,21 m
Loading volume (DIN 11741)21,3 m³23,9 m³23,9 m³20,5 m³20,5 m³
Number of knives max.31 pcs.31 pcs.31 pcs.31 pcs.31 pcs.
Theoretical chopped length43 mm43 mm43 mm43 mm43 mm
Pick-up recording width1,8 m1,8 m1,8 m1,8 m1,8 m
Track width1,85 m2,13 m1,8 m2,09 m1,85 m
Weight of basic version2950 kg3400 kg3400 kg3550 kg3550 kg
ChassisSingle axle Tandem axle Tandem axle Single axle Single axle
Single axle, 10 kph7500 kg7500 kg7500 kg7500 kg7500 kg
Single-axle, 25/40* kph, brakes7500 kg7500 kg7500 kg7500 kg7500 kg
Tandem-axle, 25/40 kph, brakes10000 kg10000 kg10000 kg10000 kg10000 kg
Single-axle, 30*/40** kph7500 kg7500 kg7500 kg7500 kg7500 kg
Tandem-axle, 30/40 kph*10000 kg10000 kg10000 kg10000 kg10000 kg
Note: *EU-2015/68, only with dual line brake system-----
EUROBOSS 250 T
 EUROBOSS 250 T
Length6,83 m
Width2,58 m
Height3,07 m
Height with opened tailgate3,31 m
Height folded down2,21 m
Number of scraper floor chains2 pcs.
Length loading area (Width 1,56)3,97 m
Loading volume (DIN 11741)16,1 m³
Number of knives max.31 pcs.
Theoretical chopped length43 mm
Pick-up recording width1,8 m
Track width2,09 m
Weight of basic version2700 kg
ChassisSingle axle
Single axle, 10 kph7500 kg
Single-axle, 25/40* kph, brakes7500 kg
Tandem-axle, 25/40 kph, brakes10000 kg
Single-axle, 30*/40** kph7500 kg
Tandem-axle, 30/40 kph*10000 kg
Note: *EU-2015/68, only with dual line brake system-
EUROBOSS 250 H
 EUROBOSS 250 H
Length6,83 m
Width2,36 m
Height3,26 m
Height with opened tailgate3,49 m
Height folded down2,39 m
Number of scraper floor chains2 pcs.
Length loading area (Width 1,56)3,97 m
Loading volume (DIN 11741)16,1 m³
Number of knives max.31 pcs.
Theoretical chopped length43 mm
Pick-up recording width1,8 m
Track width1,85 m
Weight of basic version2700 kg
ChassisSingle axle
Single axle, 10 kph7500 kg
Single-axle, 25/40* kph, brakes7500 kg
Tandem-axle, 25/40 kph, brakes10000 kg
Single-axle, 30*/40** kph7500 kg
Tandem-axle, 30/40 kph*10000 kg
Note: *EU-2015/68, only with dual line brake system-
EUROBOSS 290 T
 EUROBOSS 290 T
Length7,45 m
Width2,58 m
Height3,07 m
Height with opened tailgate3,31 m
Height folded down2,21 m
Number of scraper floor chains2 pcs.
Length loading area (Width 1,56)4,59 m
Loading volume (DIN 11741)18,7 m³
Number of knives max.31 pcs.
Theoretical chopped length43 mm
Pick-up recording width1,8 m
Track width2,09 m
Weight of basic version2825 kg
ChassisSingle axle
Single axle, 10 kph7500 kg
Single-axle, 25/40* kph, brakes7500 kg
Tandem-axle, 25/40 kph, brakes10000 kg
Single-axle, 30*/40** kph7500 kg
Tandem-axle, 30/40 kph*10000 kg
Note: *EU-2015/68, only with dual line brake system-
EUROBOSS 290 H
 EUROBOSS 290 H
Length7,45 m
Width2,36 m
Height3,26 m
Height with opened tailgate3,49 m
Height folded down2,39 m
Number of scraper floor chains2 pcs.
Length loading area (Width 1,56)4,59 m
Loading volume (DIN 11741)18,7 m³
Number of knives max.31 pcs.
Theoretical chopped length43 mm
Pick-up recording width1,8 m
Track width1,85 m
Weight of basic version2825 kg
ChassisSingle axle
Single axle, 10 kph7500 kg
Single-axle, 25/40* kph, brakes7500 kg
Tandem-axle, 25/40 kph, brakes10000 kg
Single-axle, 30*/40** kph7500 kg
Tandem-axle, 30/40 kph*10000 kg
Note: *EU-2015/68, only with dual line brake system-
EUROBOSS 330 T
 EUROBOSS 330 T
Length8,07 m
Width2,58 m
Height3,07 m
Height with opened tailgate3,31 m
Height folded down2,21 m
Number of scraper floor chains2 pcs.
Length loading area (Width 1,56)5,21 m
Loading volume (DIN 11741)21,3 m³
Number of knives max.31 pcs.
Theoretical chopped length43 mm
Pick-up recording width1,8 m
Track width2,09 m
Weight of basic version2950 kg
ChassisSingle axle
Single axle, 10 kph7500 kg
Single-axle, 25/40* kph, brakes7500 kg
Tandem-axle, 25/40 kph, brakes10000 kg
Single-axle, 30*/40** kph7500 kg
Tandem-axle, 30/40 kph*10000 kg
Note: *EU-2015/68, only with dual line brake system-
EUROBOSS 330 H
 EUROBOSS 330 H
Length8,07 m
Width2,36 m
Height3,26 m
Height with opened tailgate3,49 m
Height folded down2,39 m
Number of scraper floor chains2 pcs.
Length loading area (Width 1,56)5,21 m
Loading volume (DIN 11741)21,3 m³
Number of knives max.31 pcs.
Theoretical chopped length43 mm
Pick-up recording width1,8 m
Track width1,85 m
Weight of basic version2950 kg
ChassisSingle axle
Single axle, 10 kph7500 kg
Single-axle, 25/40* kph, brakes7500 kg
Tandem-axle, 25/40 kph, brakes10000 kg
Single-axle, 30*/40** kph7500 kg
Tandem-axle, 30/40 kph*10000 kg
Note: *EU-2015/68, only with dual line brake system-
EUROBOSS 370 T
 EUROBOSS 370 T
Length8,69 m
Width2,69 m
Height3,07 m
Height with opened tailgate3,31 m
Height folded down2,21 m
Number of scraper floor chains2 pcs.
Length loading area (Width 1,56)5,83 m
Loading volume (DIN 11741)23,9 m³
Number of knives max.31 pcs.
Theoretical chopped length43 mm
Pick-up recording width1,8 m
Track width2,13 m
Weight of basic version3400 kg
ChassisTandem axle
Single axle, 10 kph7500 kg
Single-axle, 25/40* kph, brakes7500 kg
Tandem-axle, 25/40 kph, brakes10000 kg
Single-axle, 30*/40** kph7500 kg
Tandem-axle, 30/40 kph*10000 kg
Note: *EU-2015/68, only with dual line brake system-
EUROBOSS 370 H
 EUROBOSS 370 H
Length8,69 m
Width2,36 m
Height3,26 m
Height with opened tailgate3,49 m
Height folded down2,39 m
Number of scraper floor chains2 pcs.
Length loading area (Width 1,56)5,83 m
Loading volume (DIN 11741)23,9 m³
Number of knives max.31 pcs.
Theoretical chopped length43 mm
Pick-up recording width1,8 m
Track width1,8 m
Weight of basic version3400 kg
ChassisTandem axle
Single axle, 10 kph7500 kg
Single-axle, 25/40* kph, brakes7500 kg
Tandem-axle, 25/40 kph, brakes10000 kg
Single-axle, 30*/40** kph7500 kg
Tandem-axle, 30/40 kph*10000 kg
Note: *EU-2015/68, only with dual line brake system-
EUROBOSS 330 D-T
 EUROBOSS 330 D-T
Length8,07 m
Width2,58 m
Height3,07 m
Height with opened tailgate3,31 m
Height folded down2,21 m
Number of scraper floor chains2 pcs.
Length loading area (Width 1,56)5,21 m
Loading volume (DIN 11741)20,5 m³
Number of knives max.31 pcs.
Theoretical chopped length43 mm
Pick-up recording width1,8 m
Track width2,09 m
Weight of basic version3550 kg
ChassisSingle axle
Single axle, 10 kph7500 kg
Single-axle, 25/40* kph, brakes7500 kg
Tandem-axle, 25/40 kph, brakes10000 kg
Single-axle, 30*/40** kph7500 kg
Tandem-axle, 30/40 kph*10000 kg
Note: *EU-2015/68, only with dual line brake system-
EUROBOSS 330 D-H
 EUROBOSS 330 D-H
Length8,07 m
Width2,36 m
Height3,26 m
Height with opened tailgate3,49 m
Height folded down2,39 m
Number of scraper floor chains2 pcs.
Length loading area (Width 1,56)5,21 m
Loading volume (DIN 11741)20,5 m³
Number of knives max.31 pcs.
Theoretical chopped length43 mm
Pick-up recording width1,8 m
Track width1,85 m
Weight of basic version3550 kg
ChassisSingle axle
Single axle, 10 kph7500 kg
Single-axle, 25/40* kph, brakes7500 kg
Tandem-axle, 25/40 kph, brakes10000 kg
Single-axle, 30*/40** kph7500 kg
Tandem-axle, 30/40 kph*10000 kg
Note: *EU-2015/68, only with dual line brake system-
Medien

Videos

Image gallery

Qualität


Qualität

Quality

We manufacture our products using the very latest flexible industrial methods in several locations. Everything we do is delivered to the highest possible quality.
Here, we test our products as to their suitability in field conditions in order to pass on only the very best to our customers. The testing centre is one of the most modern in agriculture worldwide and has an excellent reputation. Many other internationally-recognised manufacturers have their products tested here.
Our customers expect our machines to operate faultlessly and be completely reliable. To achieve this, we apply the highest quality standards applicable to the manufacture of agricultural machines - our own. The whole production process is monitored by our internal quality management team.
Our coating processes involve the most environmentally-friendly painting methods. Powder-coated paintwork has proven to be flexible and durable in the field. This ensures that our machines retain their value even after years of hard service.
