SERVO 4000 Heavy hitch-mounted reversible ploughs



Engineered to handle the toughest work and highest loads, working with powerful tractors and delivering an impressive output: these SERVO 4000 hitch-mounted reversible ploughs combine everything in one implement. With four to six furrows and a furrow width of up to 59 cm, an overall working width of up to 3.54 m can be achieved. To do this, the plough can be pulled by tractors with up to 360 Hp, and be used as an on-land plough.

Engineered to handle the toughest work and highest loads, working with powerful tractors and delivering an impressive output: these SERVO 4000 hitch-mounted reversible ploughs combine everything in one implement. With four to six furrows and a furrow width of up to 59 cm, an overall working width of up to 3.54 m can be achieved. To do this, the plough can be pulled by tractors with up to 360 Hp, and be used as an on-land plough.

Customer benefits



Technology

Technology

Technical data

 SERVO 4000 (4)SERVO 4000 (5)SERVO 4000 (6)
Beam dimensions140 x 140 mm140 x 140 mm140 x 140 mm
Body spacing and furrow widths95 (30-35-40-45-50-55)
102 (32-38-43-48-54-59) cm		95 (30-35-40-45-50-55)
102 (32-38-43-48-54-59) cm		95 (30-35-40-45-50-55)
102 (32-38-43-48-54-59) cm
Under frame clearance80, 90 cm80, 90 cm80, 90 cm
Power requirement140 - 280 hp170 - 320 hp180 - 360 hp
Interbody distance95
102 cm		95
102 cm		95
102 cm
Leg dimensions80 x 35 mm80 x 35 mm80 x 35 mm
Weight1630 kg1900 kg2120 kg
SERVO 4000 (4)
Beam dimensions140 x 140 mm
Body spacing and furrow widths95 (30-35-40-45-50-55)
102 (32-38-43-48-54-59) cm
Under frame clearance80, 90 cm
Power requirement140 - 280 hp
Interbody distance95
102 cm
Leg dimensions80 x 35 mm
Weight1630 kg
SERVO 4000 (5)
Beam dimensions140 x 140 mm
Body spacing and furrow widths95 (30-35-40-45-50-55)
102 (32-38-43-48-54-59) cm
Under frame clearance80, 90 cm
Power requirement170 - 320 hp
Interbody distance95
102 cm
Leg dimensions80 x 35 mm
Weight1900 kg
SERVO 4000 (6)
Beam dimensions140 x 140 mm
Body spacing and furrow widths95 (30-35-40-45-50-55)
102 (32-38-43-48-54-59) cm
Under frame clearance80, 90 cm
Power requirement180 - 360 hp
Interbody distance95
102 cm
Leg dimensions80 x 35 mm
Weight2120 kg
 SERVO 4000 N (4)SERVO 4000 N (5)SERVO 4000 N (6)
Beam dimensions140 x 140 mm140 x 140 mm140 x 140 mm
Body spacing and furrow widths95 (30-35-40-45-50-55)
102 (32-38-43-48-54-59) cm		95 (30-35-40-45-50-55)
102 (32-38-43-48-54-59) cm		95 (30-35-40-45-50-55) cm
Under frame clearance80 cm80 cm80 cm
Power requirement180 - 300 hp200 - 360 hp220 - 360 hp
Interbody distance95
102 cm		95
102 cm		95 cm
Leg dimensions80 x 35 mm80 x 35 mm80 x 35 mm
Weight1830 kg2160 kg2460 kg
SERVO 4000 N (4)
Beam dimensions140 x 140 mm
Body spacing and furrow widths95 (30-35-40-45-50-55)
102 (32-38-43-48-54-59) cm
Under frame clearance80 cm
Power requirement180 - 300 hp
Interbody distance95
102 cm
Leg dimensions80 x 35 mm
Weight1830 kg
SERVO 4000 N (5)
Beam dimensions140 x 140 mm
Body spacing and furrow widths95 (30-35-40-45-50-55)
102 (32-38-43-48-54-59) cm
Under frame clearance80 cm
Power requirement200 - 360 hp
Interbody distance95
102 cm
Leg dimensions80 x 35 mm
Weight2160 kg
SERVO 4000 N (6)
Beam dimensions140 x 140 mm
Body spacing and furrow widths95 (30-35-40-45-50-55) cm
Under frame clearance80 cm
Power requirement220 - 360 hp
Interbody distance95 cm
Leg dimensions80 x 35 mm
Weight2460 kg
 SERVO 4000 P (4)SERVO 4000 P (5)SERVO 4000 P (6)
Beam dimensions140 x 140 mm140 x 140 mm140 x 140 mm
Body spacing and furrow widths95 (30-55)
102 (32-59)
115 (35-64) cm		95 (30-55)
102 (32-59) cm		95 (30-55)
102 (32-59) cm
Under frame clearance80, 90 cm80, 90 cm80, 90 cm
Power requirement140 - 280 hp170 - 320 hp180 - 360 hp
Interbody distance95
102
115 cm		95
102 cm		95
102 cm
Leg dimensions80 x 35 mm80 x 35 mm80 x 35 mm
Weight1650 kg1930 kg2200 kg
SERVO 4000 P (4)
Beam dimensions140 x 140 mm
Body spacing and furrow widths95 (30-55)
102 (32-59)
115 (35-64) cm
Under frame clearance80, 90 cm
Power requirement140 - 280 hp
Interbody distance95
102
115 cm
Leg dimensions80 x 35 mm
Weight1650 kg
SERVO 4000 P (5)
Beam dimensions140 x 140 mm
Body spacing and furrow widths95 (30-55)
102 (32-59) cm
Under frame clearance80, 90 cm
Power requirement170 - 320 hp
Interbody distance95
102 cm
Leg dimensions80 x 35 mm
Weight1930 kg
SERVO 4000 P (6)
Beam dimensions140 x 140 mm
Body spacing and furrow widths95 (30-55)
102 (32-59) cm
Under frame clearance80, 90 cm
Power requirement180 - 360 hp
Interbody distance95
102 cm
Leg dimensions80 x 35 mm
Weight2200 kg
 SERVO 4000 PN (4)SERVO 4000 PN (5)SERVO 4000 PN (6)
Beam dimensions140 x 140 mm140 x 140 mm140 x 140 mm
Body spacing and furrow widths95 (30-55)
102 (32-59) cm		95 (30-55)
102 (32-59) cm		95 (30-55) cm
Under frame clearance80 cm80 cm80 cm
Power requirement180 - 300 hp200 - 360 hp220 - 360 hp
Interbody distance95
102 cm		95
102 cm		95 cm
Leg dimensions80 x 35 mm80 x 35 mm80 x 35 mm
Weight1850 kg2180 kg2520 kg
SERVO 4000 PN (4)
Beam dimensions140 x 140 mm
Body spacing and furrow widths95 (30-55)
102 (32-59) cm
Under frame clearance80 cm
Power requirement180 - 300 hp
Interbody distance95
102 cm
Leg dimensions80 x 35 mm
Weight1850 kg
SERVO 4000 PN (5)
Beam dimensions140 x 140 mm
Body spacing and furrow widths95 (30-55)
102 (32-59) cm
Under frame clearance80 cm
Power requirement200 - 360 hp
Interbody distance95
102 cm
Leg dimensions80 x 35 mm
Weight2180 kg
SERVO 4000 PN (6)
Beam dimensions140 x 140 mm
Body spacing and furrow widths95 (30-55) cm
Under frame clearance80 cm
Power requirement220 - 360 hp
Interbody distance95 cm
Leg dimensions80 x 35 mm
Weight2520 kg


MY POETTINGER

MyPÖTTINGER


  • Get valuable information and tips on all PÖTTINGER machines
  • Specific information on your PÖTTINGER machines in "My Machines".
  • Instruction manuals, spare parts lists, maintenance information, as well as all technical details available online
  • Machine-specific documentation for all PÖTTINGER machines built from 1997 onwards available online

www.mypoettinger.com


Medien

Media

Videos

Farmer Franz Bräuer shows the SERVO 4000 P in action
Farmer Franz Bräuer shows the SERVO 4000 P in action
Gerhard's experience with the SERVO 4000 P
Gerhard's experience with the SERVO 4000 P
SERVO 4000 - Perfect ploughing
SERVO 4000 - Perfect ploughing
Quality
Quality
We manufacture our products using the very latest flexible industrial methods in several locations. Everything we do is delivered to the highest possible quality.
Here, we test our products as to their suitability in field conditions in order to pass on only the very best to our customers. The testing centre is one of the most modern in agriculture worldwide and has an excellent reputation. Many other internationally-recognised manufacturers have their products tested here.
Our customers expect our machines to operate faultlessly and be completely reliable. To achieve this, we apply the highest quality standards applicable to the manufacture of agricultural machines - our own. The whole production process is monitored by our internal quality management team.
Our coating processes involve the most environmentally-friendly painting methods. Powder-coated paintwork has proven to be flexible and durable in the field. This ensures that our machines retain their value even after years of hard service.
