The best forage
Whether Tedding silage or hay, on level ground or hillsides - POTTINGER HIT tedders get the job done perfectly. Innovative DYNATECH rotor technology ensures a clean and tidy spread pattern with maximum forage conservation. As you would expect from PÖTTINGER the tedders ground tracking works perfectly and provides ideal conditions for harvesting high quality forage.
High performance with small tractors
With the trailed configuration, high outputs are possible even with small tractors. The trailed tedders offer working widths (DIN) of 5,20 m / 7,85 m / 8,60 m without the need for lifting power.
Whether Tedding silage or hay, on level ground or hillsides - POTTINGER HIT tedders get the job done perfectly. Innovative DYNATECH rotor technology ensures a clean and tidy spread pattern with maximum forage conservation. As you would expect from PÖTTINGER the tedders ground tracking works perfectly and provides ideal conditions for harvesting high quality forage.
High performance with small tractors
With the trailed configuration, high outputs are possible even with small tractors. The trailed tedders offer working widths (DIN) of 5,20 m / 7,85 m / 8,60 m without the need for lifting power.
Customer benefits
Technology
Technical data
| HIT 4.54 T | |||||
|---|---|---|---|---|---|
| Working width | 17'9'' (5,4 m) | ||||
| Working width DIN | 17'1'' (5,2 m) | ||||
| Transport width | 9'4'' (2,85 m) | ||||
| Transport height | 9'10'' (3 m) | ||||
| Parking height | 8'6'' (2,6 m) | ||||
| Weight | 1411 lbs (640 kg) | ||||
| Power requirement | 35 hp | ||||
| Number of rotors | 4 pcs. | ||||
| Number of arms per rotor | 6 pcs. | ||||
| Type of tines | asymmetric | ||||
| Quality of tines | Super C | ||||
| Tine security system | HEAVY DUTY as standard | ||||
| Drive system | PTO shaft | ||||
| Rotor diameter | 5'6'' (1,67 m) | ||||
| Fenceline spreading system | rigid | ||||
| Tires – rotor outside / inside | 16 x 9,5-8 / 16 x 9,5-8 |
HIT 4.54 T
| Working width | 17'9'' (5,4 m) |
| Working width DIN | 17'1'' (5,2 m) |
| Transport width | 9'4'' (2,85 m) |
| Transport height | 9'10'' (3 m) |
| Parking height | 8'6'' (2,6 m) |
| Weight | 1411 lbs (640 kg) |
| Power requirement | 35 hp |
| Number of rotors | 4 pcs. |
| Number of arms per rotor | 6 pcs. |
| Type of tines | asymmetric |
| Quality of tines | Super C |
| Tine security system | HEAVY DUTY as standard |
| Drive system | PTO shaft |
| Rotor diameter | 5'6'' (1,67 m) |
| Fenceline spreading system | rigid |
| Tires – rotor outside / inside | 16 x 9,5-8 / 16 x 9,5-8 |
| HIT 6.80 T | |||||
|---|---|---|---|---|---|
| Working width | 25'9'' (7,85 m) | ||||
| Working width DIN | 24'5'' (7,45 m) | ||||
| Transport width | 9'10'' (3 m) | ||||
| Transport height | 13'1'' (4 m) | ||||
| Parking height | 12'3'' (3,73 m) | ||||
| Weight | 2293 lbs (1040 kg) | ||||
| Power requirement | 40 hp | ||||
| Number of rotors | 6 pcs. | ||||
| Number of arms per rotor | 6 pcs. | ||||
| Type of tines | asymmetric | ||||
| Quality of tines | Super C | ||||
| Tine security system | HEAVY DUTY as standard | ||||
| Drive system | PTO shaft | ||||
| Rotor diameter | 5'6'' (1,67 m) | ||||
| Fenceline spreading system | rigid | ||||
| Tires – rotor outside / inside | 16 x 6,5-8 / 16 x 6,5-8 |
HIT 6.80 T
| Working width | 25'9'' (7,85 m) |
| Working width DIN | 24'5'' (7,45 m) |
| Transport width | 9'10'' (3 m) |
| Transport height | 13'1'' (4 m) |
| Parking height | 12'3'' (3,73 m) |
| Weight | 2293 lbs (1040 kg) |
| Power requirement | 40 hp |
| Number of rotors | 6 pcs. |
| Number of arms per rotor | 6 pcs. |
| Type of tines | asymmetric |
| Quality of tines | Super C |
| Tine security system | HEAVY DUTY as standard |
| Drive system | PTO shaft |
| Rotor diameter | 5'6'' (1,67 m) |
| Fenceline spreading system | rigid |
| Tires – rotor outside / inside | 16 x 6,5-8 / 16 x 6,5-8 |
| HIT 8.91 T | |||||
|---|---|---|---|---|---|
| Working width | 29'1'' (8,86 m) | ||||
| Working width DIN | 28'3'' (8,6 m) | ||||
| Transport width | 9'10'' (3 m) | ||||
| Transport height | 12' (3,65 m) | ||||
| Parking height | 10'8'' (3,26 m) | ||||
| Weight | 3329 lbs (1510 kg) | ||||
| Power requirement | 60 hp | ||||
| Number of rotors | 8 pcs. | ||||
| Number of arms per rotor | 6 pcs. | ||||
| Type of tines | asymmetric | ||||
| Quality of tines | Super C | ||||
| Tine security system | HEAVY DUTY as standard | ||||
| Drive system | PTO shaft | ||||
| Rotor diameter | 4'8'' (1,42 m) | ||||
| Fenceline spreading system | rigid | ||||
| Tires – rotor outside / inside | 16 x 6,5-8 / 16 x 9,5-8 | ||||
| Tires - chassis | 260/70-15,3 |
HIT 8.91 T
| Working width | 29'1'' (8,86 m) |
| Working width DIN | 28'3'' (8,6 m) |
| Transport width | 9'10'' (3 m) |
| Transport height | 12' (3,65 m) |
| Parking height | 10'8'' (3,26 m) |
| Weight | 3329 lbs (1510 kg) |
| Power requirement | 60 hp |
| Number of rotors | 8 pcs. |
| Number of arms per rotor | 6 pcs. |
| Type of tines | asymmetric |
| Quality of tines | Super C |
| Tine security system | HEAVY DUTY as standard |
| Drive system | PTO shaft |
| Rotor diameter | 4'8'' (1,42 m) |
| Fenceline spreading system | rigid |
| Tires – rotor outside / inside | 16 x 6,5-8 / 16 x 9,5-8 |
| Tires - chassis | 260/70-15,3 |
HAYTOOL ASSIST
Match your tedder to the working width of your mower to get the highest utilisation and best work quality from your machines.
The best spreading quality is achieved when the tedder completely covers the swath of mowed grass on each pass. And ideally, the tractor should drive along a forage-free lane. The forage then remains loose on top of the grass stubble, making it an easy target for the tines.
HAYTOOL ASSIST helps you quickly and easily find the right tedder for your mower.
www.mypoettinger.com/haytool-assist
MyPÖTTINGER
- Get valuable information and tips on all PÖTTINGER machines
- Specific information on your PÖTTINGER machines in "My Machines".
- Instruction manuals, spare parts lists, maintenance information, as well as all technical details available online
- Machine-specific documentation for all PÖTTINGER machines built from 1997 onwards available online
www.mypoettinger.com
Videos
HIT, HIT T Tedders - Durability
![PÖTTINGER HIT tedders [english]](https://i1.ytimg.com/vi/ZmOQuC4QgUk/mqdefault.jpg "PÖTTINGER HIT tedders [english]")
PÖTTINGER HIT tedders [english]
Pöttinger HIT / HIT T tedders
Brochures
Image gallery
Quality
We manufacture our products using the very latest flexible industrial methods in several locations. Everything we do is delivered to the highest possible quality.
Here, we test our products as to their suitability in field conditions in order to pass on only the very best to our customers. The testing centre is one of the most modern in agriculture worldwide and has an excellent reputation. Many other internationally-recognised manufacturers have their products tested here.
Our customers expect our machines to operate faultlessly and be completely reliable. To achieve this, we apply the highest quality standards applicable to the manufacture of agricultural machines - our own. The whole production process is monitored by our internal quality management team.
Our coating processes involve the most environmentally-friendly painting methods. Powder-coated paintwork has proven to be flexible and durable in the field. This ensures that our machines retain their value even after years of hard service.
