The best forage
With the new JUMBO you are always two steps ahead.
The JUMBO is a high-performance loader wagon that delivers maximum output, high efficiency, excellent reliability and the best operator convenience. It guarantees enjoyable work and high yields. The new range brings you safely through the harvesting season and is also ideal for transporting goods of all kinds at other times too.
With the new JUMBO you are always two steps ahead.
The JUMBO is a high-performance loader wagon that delivers maximum output, high efficiency, excellent reliability and the best operator convenience. It guarantees enjoyable work and high yields. The new range brings you safely through the harvesting season and is also ideal for transporting goods of all kinds at other times too.
Customer benefits
Technology
Technical data
| JUMBO 8450 DB | JUMBO 8470 | ||||
|---|---|---|---|---|---|
| Length | 35' (10,66 m) | 35' (10,66 m) | |||
| Width | 9'10'' (2,99 m) | 9'10'' (2,99 m) | |||
| Height with 26.5" tires | 12'9'' (3,89 m) | 12'9'' (3,89 m) | |||
| Number of scraper floor chains | 4 pcs. | 4 pcs. | |||
| Scraper floor motor (standard) | 2-speed | 2-speed | |||
| Loading volume (DIN 11741) | 1589'2'' ft³ (45 m³) | 1659'9'' ft³ (47 m³) | |||
| Number of knives max. | 65 pcs. | 65 pcs. | |||
| Theoretical chopped length | 0'1'' (25 mm) | 0'1'' (25 mm) | |||
| Pick-up recording width | 7'7'' (2,3 m) | 7'7'' (2,3 m) | |||
| Track width | 6'9'' (2,05 m) | 6'9'' (2,05 m) | |||
| Weight of basic version | 27668 lbs (12550 kg) | 26896 lbs (12200 kg) | |||
| Chassis | Tandem unit 20 tons | Tandem unit 20 tons | |||
| Permissible laden weight (standard) | 52911 lbs (24000 kg) | 52911 lbs (24000 kg) | |||
| Permissible laden weight max. | 68343 lbs (31000 kg) | 68343 lbs (31000 kg) | |||
| Note: *EU-2015/68, only with dual line brake system | - | - |
JUMBO 8450 DB
| Length | 35' (10,66 m) |
| Width | 9'10'' (2,99 m) |
| Height with 26.5" tires | 12'9'' (3,89 m) |
| Number of scraper floor chains | 4 pcs. |
| Scraper floor motor (standard) | 2-speed |
| Loading volume (DIN 11741) | 1589'2'' ft³ (45 m³) |
| Number of knives max. | 65 pcs. |
| Theoretical chopped length | 0'1'' (25 mm) |
| Pick-up recording width | 7'7'' (2,3 m) |
| Track width | 6'9'' (2,05 m) |
| Weight of basic version | 27668 lbs (12550 kg) |
| Chassis | Tandem unit 20 tons |
| Permissible laden weight (standard) | 52911 lbs (24000 kg) |
| Permissible laden weight max. | 68343 lbs (31000 kg) |
| Note: *EU-2015/68, only with dual line brake system | - |
JUMBO 8470
| Length | 35' (10,66 m) |
| Width | 9'10'' (2,99 m) |
| Height with 26.5" tires | 12'9'' (3,89 m) |
| Number of scraper floor chains | 4 pcs. |
| Scraper floor motor (standard) | 2-speed |
| Loading volume (DIN 11741) | 1659'9'' ft³ (47 m³) |
| Number of knives max. | 65 pcs. |
| Theoretical chopped length | 0'1'' (25 mm) |
| Pick-up recording width | 7'7'' (2,3 m) |
| Track width | 6'9'' (2,05 m) |
| Weight of basic version | 26896 lbs (12200 kg) |
| Chassis | Tandem unit 20 tons |
| Permissible laden weight (standard) | 52911 lbs (24000 kg) |
| Permissible laden weight max. | 68343 lbs (31000 kg) |
| Note: *EU-2015/68, only with dual line brake system | - |
| JUMBO 8520 DB | JUMBO 8540 | ||||
|---|---|---|---|---|---|
| Length | 39'4'' (11,98 m) | 39'4'' (11,98 m) | |||
| Width | 9'10'' (2,99 m) | 9'10'' (2,99 m) | |||
| Height with 26.5" tires | 12'9'' (3,89 m) | 12'9'' (3,89 m) | |||
| Number of scraper floor chains | 4 pcs. | 4 pcs. | |||
| Scraper floor motor (standard) | 2-speed | 2-speed | |||
| Loading volume (DIN 11741) | 1836'4'' ft³ (52 m³) | 1907' ft³ (54 m³) | |||
| Number of knives max. | 65 pcs. | 65 pcs. | |||
| Theoretical chopped length | 0'1'' (25 mm) | 0'1'' (25 mm) | |||
| Pick-up recording width | 7'7'' (2,3 m) | 7'7'' (2,3 m) | |||
| Track width | 6'9'' (2,05 m) | 6'9'' (2,05 m) | |||
| Weight of basic version | 32518 lbs (14750 kg) | 31747 lbs (14400 kg) | |||
| Chassis | Tridem unit 30 tons | Tridem unit 30 tons | |||
| Permissible laden weight (standard) | 74957 lbs (34000 kg) | 74957 lbs (34000 kg) | |||
| Permissible laden weight max. | 74957 lbs (34000 kg) | 74957 lbs (34000 kg) | |||
| Note: *EU-2015/68, only with dual line brake system | - | - |
JUMBO 8520 DB
| Length | 39'4'' (11,98 m) |
| Width | 9'10'' (2,99 m) |
| Height with 26.5" tires | 12'9'' (3,89 m) |
| Number of scraper floor chains | 4 pcs. |
| Scraper floor motor (standard) | 2-speed |
| Loading volume (DIN 11741) | 1836'4'' ft³ (52 m³) |
| Number of knives max. | 65 pcs. |
| Theoretical chopped length | 0'1'' (25 mm) |
| Pick-up recording width | 7'7'' (2,3 m) |
| Track width | 6'9'' (2,05 m) |
| Weight of basic version | 32518 lbs (14750 kg) |
| Chassis | Tridem unit 30 tons |
| Permissible laden weight (standard) | 74957 lbs (34000 kg) |
| Permissible laden weight max. | 74957 lbs (34000 kg) |
| Note: *EU-2015/68, only with dual line brake system | - |
JUMBO 8540
| Length | 39'4'' (11,98 m) |
| Width | 9'10'' (2,99 m) |
| Height with 26.5" tires | 12'9'' (3,89 m) |
| Number of scraper floor chains | 4 pcs. |
| Scraper floor motor (standard) | 2-speed |
| Loading volume (DIN 11741) | 1907' ft³ (54 m³) |
| Number of knives max. | 65 pcs. |
| Theoretical chopped length | 0'1'' (25 mm) |
| Pick-up recording width | 7'7'' (2,3 m) |
| Track width | 6'9'' (2,05 m) |
| Weight of basic version | 31747 lbs (14400 kg) |
| Chassis | Tridem unit 30 tons |
| Permissible laden weight (standard) | 74957 lbs (34000 kg) |
| Permissible laden weight max. | 74957 lbs (34000 kg) |
| Note: *EU-2015/68, only with dual line brake system | - |
