Trailed NOVACAT T mowers are ideal for cutting heavy crops. We achieve perfect three-dimensional ground tracking thanks to the fully-floating mower unit with optimised spring positions. The NOVACAT T models are available with COLLECTOR swath merging.

Trailed NOVACAT T mowers are ideal for cutting heavy crops. We achieve perfect three-dimensional ground tracking thanks to the fully-floating mower unit with optimised spring positions. The NOVACAT T models are available with COLLECTOR swath merging.

Brochures

Videos




Technology

Technical data

 NOVACAT 307 T EDNOVACAT 307 T RCBNOVACAT 3007 T EDNOVACAT 3007 T RCBNOVACAT 3507 T ED
MountingSemi-mounted Semi-mounted Semi-mounted Semi-mounted Semi-mounted
DrawbarSide drawbar Side drawbar Center-mounted drawbar Center-mounted drawbar Center-mounted drawbar
Weight4389 lbs (1991 kg)4522 lbs (2051 kg)4698 lbs (2131 kg)4828 lbs (2190 kg)4863 lbs (2206 kg)
Working width10' (3,04 m)10' (3,04 m)10' (3,04 m)10' (3,04 m)11'4'' (3,46 m)
Transport width9'10'' (3 m)9'10'' (3 m)9'10'' (3 m)9'10'' (3 m)11'3'' (3,42 m)
Transport height6'10'' (2,08 m)6'10'' (2,08 m)6'10'' (2,08 m)6'10'' (2,08 m)6'10'' (2,08 m)
Transport length20' (6100 mm)20' (6100 mm)24'10'' (7560 mm)24'10'' (7560 mm)24'10'' (7560 mm)
Conditioner width6'11'' (2120 mm)6'11'' (2120 mm)6'11'' (2120 mm)-8'4'' (2540 mm)
PTO speed1000 rpm1000 rpm1000 rpm1000 rpm1000 rpm
Mower discs7 pcs.7 pcs.7 pcs.7 pcs.8 pcs.
Mower blades14 pcs.14 pcs.14 pcs.14 pcs.16 pcs.
Power requirement75 hp75 hp75 hp75 hp85 hp
Coverage3,6 ha/h3,6 ha/h3,6 ha/h3,6 ha/h4,2 ha/h
Wear skids5 pcs.5 pcs.5 pcs.5 pcs.6 pcs.
High-cut skids5 pcs.5 pcs.5 pcs.5 pcs.6 pcs.
High-cut skids inside / outside1 pcs.1 pcs.1 pcs.1 pcs.1 pcs.
Tires - chassis340/55-16 340/55-16 340/55-16 340/55-16 340/55-16
Swath width with conditioner min6'3'' (1,9 m)5'7'' (1,7 m)6'3'' (1,9 m)5'7'' (1,7 m)7'3'' (2,2 m)
Swath width with conditioner max8'10'' (2,7 m)8'2'' (2,5 m)8'10'' (2,7 m)8'2'' (2,5 m)10'2'' (3,1 m)
 NOVACAT 3507 T RCBNOVACAT 3507 T ED COLLECTORNOVACAT 3507 T RCB COLLECTOR
MountingSemi-mounted Semi-mounted Semi-mounted
DrawbarCenter-mounted drawbar Center-mounted drawbar Center-mounted drawbar
Weight5040 lbs (2286 kg)6228 lbs (2825 kg)6371 lbs (2890 kg)
Working width11'4'' (3,46 m)11'4'' (3,46 m)11'4'' (3,46 m)
Transport width11'3'' (3,42 m)11'3'' (3,42 m)11'3'' (3,42 m)
Transport height6'10'' (2,08 m)6'10'' (2,08 m)6'10'' (2,08 m)
Transport length24'10'' (7560 mm)28'3'' (8600 mm)28'3'' (8600 mm)
Conditioner width-8'4'' (2540 mm)-
PTO speed1000 rpm1000 rpm1000 rpm
Mower discs8 pcs.8 pcs.8 pcs.
Mower blades16 pcs.16 pcs.16 pcs.
Power requirement85 hp85 hp85 hp
Coverage4,2 ha/h4,2 ha/h4,2 ha/h
Wear skids6 pcs.6 pcs.6 pcs.
High-cut skids6 pcs.6 pcs.6 pcs.
High-cut skids inside / outside1 pcs.1 pcs.1 pcs.
Tires - chassis340/55-16 340/55-16 340/55-16
Swath width with conditioner min7'3'' (2,2 m)--
Swath width with conditioner max9'10'' (3 m)--
NOVACAT 307 T ED
 NOVACAT 307 T ED
MountingSemi-mounted
DrawbarSide drawbar
Weight4389 lbs (1991 kg)
Working width10' (3,04 m)
Transport width9'10'' (3 m)
Transport height6'10'' (2,08 m)
Transport length20' (6100 mm)
Conditioner width6'11'' (2120 mm)
PTO speed1000 rpm
Mower discs7 pcs.
Mower blades14 pcs.
Power requirement75 hp
Coverage3,6 ha/h
Wear skids5 pcs.
High-cut skids5 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min6'3'' (1,9 m)
Swath width with conditioner max8'10'' (2,7 m)
NOVACAT 307 T RCB
 NOVACAT 307 T RCB
MountingSemi-mounted
DrawbarSide drawbar
Weight4522 lbs (2051 kg)
Working width10' (3,04 m)
Transport width9'10'' (3 m)
Transport height6'10'' (2,08 m)
Transport length20' (6100 mm)
Conditioner width6'11'' (2120 mm)
PTO speed1000 rpm
Mower discs7 pcs.
Mower blades14 pcs.
Power requirement75 hp
Coverage3,6 ha/h
Wear skids5 pcs.
High-cut skids5 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min5'7'' (1,7 m)
Swath width with conditioner max8'2'' (2,5 m)
NOVACAT 3007 T ED
 NOVACAT 3007 T ED
MountingSemi-mounted
DrawbarCenter-mounted drawbar
Weight4698 lbs (2131 kg)
Working width10' (3,04 m)
Transport width9'10'' (3 m)
Transport height6'10'' (2,08 m)
Transport length24'10'' (7560 mm)
Conditioner width6'11'' (2120 mm)
PTO speed1000 rpm
Mower discs7 pcs.
Mower blades14 pcs.
Power requirement75 hp
Coverage3,6 ha/h
Wear skids5 pcs.
High-cut skids5 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min6'3'' (1,9 m)
Swath width with conditioner max8'10'' (2,7 m)
NOVACAT 3007 T RCB
 NOVACAT 3007 T RCB
MountingSemi-mounted
DrawbarCenter-mounted drawbar
Weight4828 lbs (2190 kg)
Working width10' (3,04 m)
Transport width9'10'' (3 m)
Transport height6'10'' (2,08 m)
Transport length24'10'' (7560 mm)
Conditioner width-
PTO speed1000 rpm
Mower discs7 pcs.
Mower blades14 pcs.
Power requirement75 hp
Coverage3,6 ha/h
Wear skids5 pcs.
High-cut skids5 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min5'7'' (1,7 m)
Swath width with conditioner max8'2'' (2,5 m)
NOVACAT 3507 T ED
 NOVACAT 3507 T ED
MountingSemi-mounted
DrawbarCenter-mounted drawbar
Weight4863 lbs (2206 kg)
Working width11'4'' (3,46 m)
Transport width11'3'' (3,42 m)
Transport height6'10'' (2,08 m)
Transport length24'10'' (7560 mm)
Conditioner width8'4'' (2540 mm)
PTO speed1000 rpm
Mower discs8 pcs.
Mower blades16 pcs.
Power requirement85 hp
Coverage4,2 ha/h
Wear skids6 pcs.
High-cut skids6 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min7'3'' (2,2 m)
Swath width with conditioner max10'2'' (3,1 m)
NOVACAT 3507 T RCB
 NOVACAT 3507 T RCB
MountingSemi-mounted
DrawbarCenter-mounted drawbar
Weight5040 lbs (2286 kg)
Working width11'4'' (3,46 m)
Transport width11'3'' (3,42 m)
Transport height6'10'' (2,08 m)
Transport length24'10'' (7560 mm)
Conditioner width-
PTO speed1000 rpm
Mower discs8 pcs.
Mower blades16 pcs.
Power requirement85 hp
Coverage4,2 ha/h
Wear skids6 pcs.
High-cut skids6 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min7'3'' (2,2 m)
Swath width with conditioner max9'10'' (3 m)
NOVACAT 3507 T ED COLLECTOR
 NOVACAT 3507 T ED COLLECTOR
MountingSemi-mounted
DrawbarCenter-mounted drawbar
Weight6228 lbs (2825 kg)
Working width11'4'' (3,46 m)
Transport width11'3'' (3,42 m)
Transport height6'10'' (2,08 m)
Transport length28'3'' (8600 mm)
Conditioner width8'4'' (2540 mm)
PTO speed1000 rpm
Mower discs8 pcs.
Mower blades16 pcs.
Power requirement85 hp
Coverage4,2 ha/h
Wear skids6 pcs.
High-cut skids6 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min-
Swath width with conditioner max-
NOVACAT 3507 T RCB COLLECTOR
 NOVACAT 3507 T RCB COLLECTOR
MountingSemi-mounted
DrawbarCenter-mounted drawbar
Weight6371 lbs (2890 kg)
Working width11'4'' (3,46 m)
Transport width11'3'' (3,42 m)
Transport height6'10'' (2,08 m)
Transport length28'3'' (8600 mm)
Conditioner width-
PTO speed1000 rpm
Mower discs8 pcs.
Mower blades16 pcs.
Power requirement85 hp
Coverage4,2 ha/h
Wear skids6 pcs.
High-cut skids6 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min-
Swath width with conditioner max-
