Best seed germination
Single-disc coulters and DUAL DISC double-disc coulters are available for planting cereals. PCS integrates precision seed drilling technology into a pneumatic seed drill, making you independent from single seed drills. This means greater flexibility and more cost efficient operation.
Single-disc coulters and DUAL DISC double-disc coulters are available for planting cereals. PCS integrates precision seed drilling technology into a pneumatic seed drill, making you independent from single seed drills. This means greater flexibility and more cost efficient operation.
Customer benefits
Technology
Technical data
| AEROSEM 3002 ADD | AEROSEM 3502 ADD | AEROSEM 4002 ADD | |||
|---|---|---|---|---|---|
| Working width | 3 m | 3,5 m | 4 m | ||
| Seed hopper volume | 1250 l | 1250 l | 1250 l | ||
| Row spacing | 15 12,5 cm | 12,5 cm | 15 12,5 cm | ||
| Coulter pressure (Maximum) | 50 kg | 50 kg | 50 kg | ||
| Transport width | 3 m | 3,5 m | 4 m | ||
| Filling height of seed hopper | - | - | - | ||
| Number of rows | 20 24 pcs. | 28 pcs. | 26 32 pcs. | ||
| Coulter spacing (Front to rear) | 30 cm | 30 cm | 30 cm | ||
| Min. oil flow req. for fan | 35 l | 35 l | 35 l | ||
| Oil flowrate for PCS drive | 25 l | 25 l | 25 l | ||
| Weight with DualDisc | 1275 kg | 1430 kg | 1612 kg |
AEROSEM 3002 ADD
| Working width | 3 m |
| Seed hopper volume | 1250 l |
| Row spacing | 15 12,5 cm |
| Coulter pressure (Maximum) | 50 kg |
| Transport width | 3 m |
| Filling height of seed hopper | - |
| Number of rows | 20 24 pcs. |
| Coulter spacing (Front to rear) | 30 cm |
| Min. oil flow req. for fan | 35 l |
| Oil flowrate for PCS drive | 25 l |
| Weight with DualDisc | 1275 kg |
AEROSEM 3502 ADD
| Working width | 3,5 m |
| Seed hopper volume | 1250 l |
| Row spacing | 12,5 cm |
| Coulter pressure (Maximum) | 50 kg |
| Transport width | 3,5 m |
| Filling height of seed hopper | - |
| Number of rows | 28 pcs. |
| Coulter spacing (Front to rear) | 30 cm |
| Min. oil flow req. for fan | 35 l |
| Oil flowrate for PCS drive | 25 l |
| Weight with DualDisc | 1430 kg |
AEROSEM 4002 ADD
| Working width | 4 m |
| Seed hopper volume | 1250 l |
| Row spacing | 15 12,5 cm |
| Coulter pressure (Maximum) | 50 kg |
| Transport width | 4 m |
| Filling height of seed hopper | - |
| Number of rows | 26 32 pcs. |
| Coulter spacing (Front to rear) | 30 cm |
| Min. oil flow req. for fan | 35 l |
| Oil flowrate for PCS drive | 25 l |
| Weight with DualDisc | 1612 kg |
| AEROSEM 3002 A | AEROSEM 3502 A | AEROSEM 4002 A | |||
|---|---|---|---|---|---|
| Working width | 3 m | 3,5 m | 4 m | ||
| Seed hopper volume | 1250 l | 1250 l | 1250 l | ||
| Row spacing | 15 12,5 cm | 12,5 cm | 15 12,5 cm | ||
| Coulter pressure (Maximum) | 25 kg | 25 kg | 25 kg | ||
| Transport width | 3 m | 3,5 m | 4 m | ||
| Filling height of seed hopper | 196 cm | 196 cm | 196 cm | ||
| Number of rows | 20 24 pcs. | 28 pcs. | 26 32 pcs. | ||
| Coulter spacing Single disc coulter | 30 cm | 30 cm | 30 cm | ||
| Min. oil flow req. for fan | 35 l | 35 l | 35 l | ||
| Weight with disc shares | 1082 kg | 1239 kg | 1332 kg |
AEROSEM 3002 A
| Working width | 3 m |
| Seed hopper volume | 1250 l |
| Row spacing | 15 12,5 cm |
| Coulter pressure (Maximum) | 25 kg |
| Transport width | 3 m |
| Filling height of seed hopper | 196 cm |
| Number of rows | 20 24 pcs. |
| Coulter spacing Single disc coulter | 30 cm |
| Min. oil flow req. for fan | 35 l |
| Weight with disc shares | 1082 kg |
AEROSEM 3502 A
| Working width | 3,5 m |
| Seed hopper volume | 1250 l |
| Row spacing | 12,5 cm |
| Coulter pressure (Maximum) | 25 kg |
| Transport width | 3,5 m |
| Filling height of seed hopper | 196 cm |
| Number of rows | 28 pcs. |
| Coulter spacing Single disc coulter | 30 cm |
| Min. oil flow req. for fan | 35 l |
| Weight with disc shares | 1239 kg |
AEROSEM 4002 A
| Working width | 4 m |
| Seed hopper volume | 1250 l |
| Row spacing | 15 12,5 cm |
| Coulter pressure (Maximum) | 25 kg |
| Transport width | 4 m |
| Filling height of seed hopper | 196 cm |
| Number of rows | 26 32 pcs. |
| Coulter spacing Single disc coulter | 30 cm |
| Min. oil flow req. for fan | 35 l |
| Weight with disc shares | 1332 kg |
METERING WHEEL ASSIST
Choose the right metering wheel for your seed material simply by using METERING WHEEL ASSIST on your smartphone, tablet or PC. Get the new app from the App Store now (for iOS operating systems).
To the METERING WHEEL ASSIST app: https://www.poettinger.at/metering-wheel-assist/
To the iOS app: https://itunes.apple.com/de/app/p%C3%B6tsem/id1434048370?mt=8
TRAMLINE ASSIST
To set up the optimal tramline system, you need to synchronise your machinery. TRAMLINE ASSIST helps you to do this. When choosing your seed drill, parameters such as the working width of your crop care machines, track and tyre widths are critical for optimising tramlining. TRAMLINE ASSIST identifies the tramline rhythm for you, the position of the tramline rows, and the number of rows that need to be switched off.
www.mypoettinger.com/tramline-assist
MyPÖTTINGER
- Get valuable information and tips on all PÖTTINGER machines
- Specific information on your PÖTTINGER machines in "My Machines".
- Instruction manuals, spare parts lists, maintenance information, as well as all technical details available online
- Machine-specific documentation for all PÖTTINGER machines built from 1997 onwards available online
www.mypoettinger.com
Videos
AEROSEM ADD seed drill - PCS conversion for precision sowing
PÖTTINGER AEROSEM DUPLEX SEED Maize seeding in twin rows
![Animation IDS [english]](https://i1.ytimg.com/vi/o4RYHZKkOFY/mqdefault.jpg "Animation IDS [english]")
Animation IDS [english]
Animation PCS (Precision Combi Seeding)
![PÖTTINGER AEROSEM Pneumatic seed drills [english]](https://i1.ytimg.com/vi/-k7sCRuvqA8/mqdefault.jpg "PÖTTINGER AEROSEM Pneumatic seed drills [english]")
PÖTTINGER AEROSEM Pneumatic seed drills [english]
Brochures
3D animations
Image gallery
Quality
We manufacture our products using the very latest flexible industrial methods in several locations. Everything we do is delivered to the highest possible quality.
Here, we test our products as to their suitability in field conditions in order to pass on only the very best to our customers. The testing centre is one of the most modern in agriculture worldwide and has an excellent reputation. Many other internationally-recognised manufacturers have their products tested here.
Our customers expect our machines to operate faultlessly and be completely reliable. To achieve this, we apply the highest quality standards applicable to the manufacture of agricultural machines - our own. The whole production process is monitored by our internal quality management team.
Our coating processes involve the most environmentally-friendly painting methods. Powder-coated paintwork has proven to be flexible and durable in the field. This ensures that our machines retain their value even after years of hard service.
