The variable chamber balers have three endless belts with a hydraulically– adjustable pressure–controlled belt tensioner. The three endless belts make sure the bale rotates in every situation, even with short chopped crop material.

The variable chamber balers have three endless belts with a hydraulically– adjustable pressure–controlled belt tensioner. The three endless belts make sure the bale rotates in every situation, even with short chopped crop material.




Technology

Technical data

 IMPRESS 155 V
IMPRESS 185 V
Bale diameter0,8 - 1,55 0,9 - 1,85
winder diameter--
Bale width1,2 m1,2 m
Power requirement70 hp70 hp
PTO speed540 rpm540 rpm
Pick-up recording width2,05 m2,05 m
Length4,9 m5,11 m
Width2,62 m2,62 m
Height2,83 m3,1 m
Tyres500/50-17 500/50-17
Weight of basic version4500 kg4600 kg
IMPRESS 155 V
 IMPRESS 155 V
Bale diameter0,8 - 1,55
winder diameter-
Bale width1,2 m
Power requirement70 hp
PTO speed540 rpm
Pick-up recording width2,05 m
Length4,9 m
Width2,62 m
Height2,83 m
Tyres500/50-17
Weight of basic version4500 kg
IMPRESS 185 V
 IMPRESS 185 V
Bale diameter0,9 - 1,85
winder diameter-
Bale width1,2 m
Power requirement70 hp
PTO speed540 rpm
Pick-up recording width2,05 m
Length5,11 m
Width2,62 m
Height3,1 m
Tyres500/50-17
Weight of basic version4600 kg
 IMPRESS 155 V MASTERIMPRESS 185 V MASTER
Bale diameter0,8 - 1,55 0,9 - 1,85
winder diameter--
Bale width1,2 m1,2 m
Power requirement80 hp80 hp
PTO speed540 rpm540 rpm
2,05 m2,05 m
Number of knives max.16 pcs.16 pcs.
Knife spacing72 mm72 mm
Length4,9 m5,11 m
Width2,62 m2,62 m
Height2,83 m3,1 m
Tyres380/55-17 380/55-17
Weight of basic version4750 kg4850 kg
IMPRESS 155 V MASTER
 IMPRESS 155 V MASTER
Bale diameter0,8 - 1,55
winder diameter-
Bale width1,2 m
Power requirement80 hp
PTO speed540 rpm
2,05 m
Number of knives max.16 pcs.
Knife spacing72 mm
Length4,9 m
Width2,62 m
Height2,83 m
Tyres380/55-17
Weight of basic version4750 kg
IMPRESS 185 V MASTER
 IMPRESS 185 V MASTER
Bale diameter0,9 - 1,85
winder diameter-
Bale width1,2 m
Power requirement80 hp
PTO speed540 rpm
2,05 m
Number of knives max.16 pcs.
Knife spacing72 mm
Length5,11 m
Width2,62 m
Height3,1 m
Tyres380/55-17
Weight of basic version4850 kg
 IMPRESS 155 V PROIMPRESS 185 V PRO
Bale diameter0,8 - 1,55 0,9 - 1,85
winder diameter--
Bale width1,2 m1,2 m
Power requirement100 hp100 hp
PTO speed1000 rpm1000 rpm
2,3 m2,3 m
Number of knives max.32 pcs.32 pcs.
Knife spacing36 mm36 mm
Length4,9 m5,11 m
Width2,83 m2,83 m
Height2,83 m3,1 m
Tyres500/50-17 500/50-17
Weight of basic version5000 kg5100 kg
IMPRESS 155 V PRO
 IMPRESS 155 V PRO
Bale diameter0,8 - 1,55
winder diameter-
Bale width1,2 m
Power requirement100 hp
PTO speed1000 rpm
2,3 m
Number of knives max.32 pcs.
Knife spacing36 mm
Length4,9 m
Width2,83 m
Height2,83 m
Tyres500/50-17
Weight of basic version5000 kg
IMPRESS 185 V PRO
 IMPRESS 185 V PRO
Bale diameter0,9 - 1,85
winder diameter-
Bale width1,2 m
Power requirement100 hp
PTO speed1000 rpm
2,3 m
Number of knives max.32 pcs.
Knife spacing36 mm
Length5,11 m
Width2,83 m
Height3,1 m
Tyres500/50-17
Weight of basic version5100 kg
Medien

Image gallery

Qualität


Qualität

Quality

We manufacture our products using the very latest flexible industrial methods in several locations. Everything we do is delivered to the highest possible quality.
Here, we test our products as to their suitability in field conditions in order to pass on only the very best to our customers. The testing centre is one of the most modern in agriculture worldwide and has an excellent reputation. Many other internationally-recognised manufacturers have their products tested here.
Our customers expect our machines to operate faultlessly and be completely reliable. To achieve this, we apply the highest quality standards applicable to the manufacture of agricultural machines - our own. The whole production process is monitored by our internal quality management team.
Our coating processes involve the most environmentally-friendly painting methods. Powder-coated paintwork has proven to be flexible and durable in the field. This ensures that our machines retain their value even after years of hard service.
