The highest forage quality
EUROPROFI 5010 L COMBILINE | EUROPROFI 5010 D COMBILINE | ||||
---|---|---|---|---|---|
Loading volume (DIN 11741) | 29 m³ | 28 m³ | |||
Theoretical chopped length | 39 mm | 39 mm | |||
Number of knives max. | 35 pcs. | 35 pcs. | |||
Pick-up recording width | 1,85 m | 1,85 m | |||
Length | 9,12 m | 9,61 m | |||
Width | 2,67 m | 2,67 m | |||
Height | 3,55 m | 3,55 m | |||
Height with ropes for roof | + 325 mm | + 325 mm | |||
Number of scraper floor chains | 4 pcs. | 4 pcs. | |||
Scraper floor motor (standard) | 1-speed | 1-speed | |||
Scraper floor motor (option) | 2-speed | 2-speed | |||
Length loading area (Width 2,1) | 6,36 m | 6,1 m | |||
Loading volume with medium compression | 50 m³ | 50 m³ | |||
Track width | 1,95 m | 1,95 m | |||
Weight of basic version | 7150 kg | 7650 kg | |||
Chassis | Tandem axle | Tandem axle | |||
Permissible laden weight (standard) | 18000 kg | 18000 kg | |||
Permissible laden weight max. | 21000 kg | 21000 kg | |||
Tandem-axle, 25/40 kph | 18000 kg | 18000 kg | |||
Tandem-axle, 30/40 kph* | 18000 kg | 18000 kg | |||
Tandem-axle, 30/40 kph* max. | 21000 kg | 21000 kg | |||
Note: *EU-2015/68, only with dual line brake system | - | - |
Loading volume (DIN 11741) | 29 m³ |
Theoretical chopped length | 39 mm |
Number of knives max. | 35 pcs. |
Pick-up recording width | 1,85 m |
Length | 9,12 m |
Width | 2,67 m |
Height | 3,55 m |
Height with ropes for roof | + 325 mm |
Number of scraper floor chains | 4 pcs. |
Scraper floor motor (standard) | 1-speed |
Scraper floor motor (option) | 2-speed |
Length loading area (Width 2,1) | 6,36 m |
Loading volume with medium compression | 50 m³ |
Track width | 1,95 m |
Weight of basic version | 7150 kg |
Chassis | Tandem axle |
Permissible laden weight (standard) | 18000 kg |
Permissible laden weight max. | 21000 kg |
Tandem-axle, 25/40 kph | 18000 kg |
Tandem-axle, 30/40 kph* | 18000 kg |
Tandem-axle, 30/40 kph* max. | 21000 kg |
Note: *EU-2015/68, only with dual line brake system | - |
Loading volume (DIN 11741) | 28 m³ |
Theoretical chopped length | 39 mm |
Number of knives max. | 35 pcs. |
Pick-up recording width | 1,85 m |
Length | 9,61 m |
Width | 2,67 m |
Height | 3,55 m |
Height with ropes for roof | + 325 mm |
Number of scraper floor chains | 4 pcs. |
Scraper floor motor (standard) | 1-speed |
Scraper floor motor (option) | 2-speed |
Length loading area (Width 2,1) | 6,1 m |
Loading volume with medium compression | 50 m³ |
Track width | 1,95 m |
Weight of basic version | 7650 kg |
Chassis | Tandem axle |
Permissible laden weight (standard) | 18000 kg |
Permissible laden weight max. | 21000 kg |
Tandem-axle, 25/40 kph | 18000 kg |
Tandem-axle, 30/40 kph* | 18000 kg |
Tandem-axle, 30/40 kph* max. | 21000 kg |
Note: *EU-2015/68, only with dual line brake system | - |
EUROPROFI 5510 L COMBILINE | EUROPROFI 5510 D COMBILINE | ||||
---|---|---|---|---|---|
Loading volume (DIN 11741) | 32 m³ | 31 m³ | |||
Theoretical chopped length | 39 mm | 39 mm | |||
Number of knives max. | 35 pcs. | 35 pcs. | |||
Pick-up recording width | 1,85 m | 1,85 m | |||
Length | 9,81 m | 10,28 m | |||
Width | 2,67 m | 2,67 m | |||
Height | 3,55 m | 3,55 m | |||
Height with ropes for roof | + 325 mm | + 325 mm | |||
Number of scraper floor chains | 4 pcs. | 4 pcs. | |||
Scraper floor motor (standard) | 2-speed | 2-speed | |||
Length loading area (Width 2,1) | 7,04 m | 6,79 m | |||
Loading volume with medium compression | 55 m³ | 55 m³ | |||
Track width | 1,95 m | 1,95 m | |||
Weight of basic version | 7350 kg | 7850 kg | |||
Chassis | Tandem axle | Tandem axle | |||
Permissible laden weight (standard) | 18000 kg | 18000 kg | |||
Permissible laden weight max. | 21000 kg | 21000 kg | |||
Tandem-axle, 25/40 kph | 18000 kg | 18000 kg | |||
Tandem-axle, 30/40 kph* | 18000 kg | 18000 kg | |||
Tandem-axle, 30/40 kph* max. | 21000 kg | 21000 kg | |||
Note: *EU-2015/68, only with dual line brake system | - | - |
Loading volume (DIN 11741) | 32 m³ |
Theoretical chopped length | 39 mm |
Number of knives max. | 35 pcs. |
Pick-up recording width | 1,85 m |
Length | 9,81 m |
Width | 2,67 m |
Height | 3,55 m |
Height with ropes for roof | + 325 mm |
Number of scraper floor chains | 4 pcs. |
Scraper floor motor (standard) | 2-speed |
Length loading area (Width 2,1) | 7,04 m |
Loading volume with medium compression | 55 m³ |
Track width | 1,95 m |
Weight of basic version | 7350 kg |
Chassis | Tandem axle |
Permissible laden weight (standard) | 18000 kg |
Permissible laden weight max. | 21000 kg |
Tandem-axle, 25/40 kph | 18000 kg |
Tandem-axle, 30/40 kph* | 18000 kg |
Tandem-axle, 30/40 kph* max. | 21000 kg |
Note: *EU-2015/68, only with dual line brake system | - |
Loading volume (DIN 11741) | 31 m³ |
Theoretical chopped length | 39 mm |
Number of knives max. | 35 pcs. |
Pick-up recording width | 1,85 m |
Length | 10,28 m |
Width | 2,67 m |
Height | 3,55 m |
Height with ropes for roof | + 325 mm |
Number of scraper floor chains | 4 pcs. |
Scraper floor motor (standard) | 2-speed |
Length loading area (Width 2,1) | 6,79 m |
Loading volume with medium compression | 55 m³ |
Track width | 1,95 m |
Weight of basic version | 7850 kg |
Chassis | Tandem axle |
Permissible laden weight (standard) | 18000 kg |
Permissible laden weight max. | 21000 kg |
Tandem-axle, 25/40 kph | 18000 kg |
Tandem-axle, 30/40 kph* | 18000 kg |
Tandem-axle, 30/40 kph* max. | 21000 kg |
Note: *EU-2015/68, only with dual line brake system | - |
