The perfect flow

The new IMPRESS 3000 series are professional class round balers. Thanks to the innovative crop flow, the IMPRESS delivers the highest capacity, with maximum forage conservation and the lowest power requirement.

The baling chamber is suitable for all crops in all operating conditions. By using up to 32 knives, you can achieve the best chopping quality right up to the edge of the bale. The unique EASY MOVE knife bank, which can be pulled out from the side, gives you a whole new experience of changing knives on a round baler.

For all operating conditions

The IMPRESS V MASTER and PRO are variable chamber balers that are designed for use in all crops. Thanks to the tangential flow of crop into the baling chamber the bale always starts reliably even with short-chopped dry straw or wet silage. These models have chopping systems with 16 or 32 knives.

The IMPRESS V has no chopping system and is specially designed for baling dry material.

The perfect flow

The new IMPRESS 3000 series are professional class round balers. Thanks to the innovative crop flow, the IMPRESS delivers the highest capacity, with maximum forage conservation and the lowest power requirement.

The baling chamber is suitable for all crops in all operating conditions. By using up to 32 knives, you can achieve the best chopping quality right up to the edge of the bale. The unique EASY MOVE knife bank, which can be pulled out from the side, gives you a whole new experience of changing knives on a round baler.

For all operating conditions

The IMPRESS V MASTER and PRO are variable chamber balers that are designed for use in all crops. Thanks to the tangential flow of crop into the baling chamber the bale always starts reliably even with short-chopped dry straw or wet silage. These models have chopping systems with 16 or 32 knives.

The IMPRESS V has no chopping system and is specially designed for baling dry material.




Technology

Technical data

 IMPRESS 3160 VIMPRESS 3190 VIMPRESS 155 VIMPRESS 185 V
Bale diameter0,8 - 1,55 0,9 - 1,85 0,8 - 1,55 0,9 - 1,85
winder diameter----
Bale width1,2 m1,2 m1,2 m1,2 m
Power requirement70 hp70 hp70 hp70 hp
PTO speed540 rpm540 rpm540 rpm540 rpm
Pick-up recording width2,05 m2,05 m2,05 m2,05 m
Length4,9 m5,11 m4,9 m5,11 m
Width2,62 m2,62 m2,62 m2,62 m
Height2,83 m3,1 m2,83 m3,1 m
Tyres500/50-17 500/50-17 500/50-17 500/50-17
Weight of basic version4500 kg4600 kg4500 kg4600 kg
IMPRESS 3160 V
Bale diameter0,8 - 1,55
winder diameter-
Bale width1,2 m
Power requirement70 hp
PTO speed540 rpm
Pick-up recording width2,05 m
Length4,9 m
Width2,62 m
Height2,83 m
Tyres500/50-17
Weight of basic version4500 kg
IMPRESS 3190 V
Bale diameter0,9 - 1,85
winder diameter-
Bale width1,2 m
Power requirement70 hp
PTO speed540 rpm
Pick-up recording width2,05 m
Length5,11 m
Width2,62 m
Height3,1 m
Tyres500/50-17
Weight of basic version4600 kg
IMPRESS 155 V
Bale diameter0,8 - 1,55
winder diameter-
Bale width1,2 m
Power requirement70 hp
PTO speed540 rpm
Pick-up recording width2,05 m
Length4,9 m
Width2,62 m
Height2,83 m
Tyres500/50-17
Weight of basic version4500 kg
IMPRESS 185 V
Bale diameter0,9 - 1,85
winder diameter-
Bale width1,2 m
Power requirement70 hp
PTO speed540 rpm
Pick-up recording width2,05 m
Length5,11 m
Width2,62 m
Height3,1 m
Tyres500/50-17
Weight of basic version4600 kg
 IMPRESS 3160 V MASTERIMPRESS 3190 V MASTER
Bale diameter0,8 - 1,55 0,9 - 1,85
winder diameter--
Bale width1,2 m1,2 m
Power requirement80 hp80 hp
PTO speed540 rpm540 rpm
Pick-up width (DIN 11220)2,05 m2,05 m
Number of knives max.16 pcs.16 pcs.
Knife spacing72 mm72 mm
Length4,9 m5,11 m
Width2,62 m2,62 m
Height2,83 m3,1 m
Tyres380/55-17 380/55-17
Weight of basic version4750 kg4850 kg
IMPRESS 3160 V MASTER
Bale diameter0,8 - 1,55
winder diameter-
Bale width1,2 m
Power requirement80 hp
PTO speed540 rpm
Pick-up width (DIN 11220)2,05 m
Number of knives max.16 pcs.
Knife spacing72 mm
Length4,9 m
Width2,62 m
Height2,83 m
Tyres380/55-17
Weight of basic version4750 kg
IMPRESS 3190 V MASTER
Bale diameter0,9 - 1,85
winder diameter-
Bale width1,2 m
Power requirement80 hp
PTO speed540 rpm
Pick-up width (DIN 11220)2,05 m
Number of knives max.16 pcs.
Knife spacing72 mm
Length5,11 m
Width2,62 m
Height3,1 m
Tyres380/55-17
Weight of basic version4850 kg
 IMPRESS 3160 V PROIMPRESS 3190 V PRO
Bale diameter0,8 - 1,55 0,9 - 1,85
winder diameter--
Bale width1,2 m1,2 m
Power requirement100 hp100 hp
PTO speed1000 rpm1000 rpm
Pick-up width (DIN 11220)2,3 m2,3 m
Number of knives max.32 pcs.32 pcs.
Knife spacing36 mm36 mm
Length4,9 m5,11 m
Width2,83 m2,83 m
Height2,83 m3,1 m
Tyres500/50-17 500/50-17
Weight of basic version5000 kg5100 kg
IMPRESS 3160 V PRO
Bale diameter0,8 - 1,55
winder diameter-
Bale width1,2 m
Power requirement100 hp
PTO speed1000 rpm
Pick-up width (DIN 11220)2,3 m
Number of knives max.32 pcs.
Knife spacing36 mm
Length4,9 m
Width2,83 m
Height2,83 m
Tyres500/50-17
Weight of basic version5000 kg
IMPRESS 3190 V PRO
Bale diameter0,9 - 1,85
winder diameter-
Bale width1,2 m
Power requirement100 hp
PTO speed1000 rpm
Pick-up width (DIN 11220)2,3 m
Number of knives max.32 pcs.
Knife spacing36 mm
Length5,11 m
Width2,83 m
Height3,1 m
Tyres500/50-17
Weight of basic version5100 kg


MyPÖTTINGER

MyPÖTTINGER


  • Get valuable information and tips on all PÖTTINGER machines
  • Specific information on your PÖTTINGER machines in "My Machines".
  • Instruction manuals, spare parts lists, maintenance information, as well as all technical details available online
  • Machine-specific documentation for all PÖTTINGER machines built from 1997 onwards available online

www.mypoettinger.com


Medien

Videos

Qualität


Qualität

Quality

We manufacture our products using the very latest flexible industrial methods in several locations. Everything we do is delivered to the highest possible quality.
Here, we test our products as to their suitability in field conditions in order to pass on only the very best to our customers. The testing centre is one of the most modern in agriculture worldwide and has an excellent reputation. Many other internationally-recognised manufacturers have their products tested here.
Our customers expect our machines to operate faultlessly and be completely reliable. To achieve this, we apply the highest quality standards applicable to the manufacture of agricultural machines - our own. The whole production process is monitored by our internal quality management team.
Our coating processes involve the most environmentally-friendly painting methods. Powder-coated paintwork has proven to be flexible and durable in the field. This ensures that our machines retain their value even after years of hard service.
